Pure Sine Wave Power Inverter
Pure Sine Wave Power Inverter - 图片 2
Pure Sine Wave Power Inverter - 图片 3
Pure Sine Wave Power Inverter - 图片 4
Pure Sine Wave Power Inverter - 图片 5
Pure Sine Wave Power Inverter - 图片 6

Pure Sine Wave Power Inverter

Model No PSW8300 PSW8600 PSW81200 PSW81500 PSW82000 PSW83000
Input Voltage DC 12V (DC 11-15V)
DC 24V(DC 22-30V)
Output Voltage AC 100V±10%,AC 110V±10%,AC 220-240V
Output Frequency 55±3Hz,6O±3Hz,50±3Hz
USB Output DC 5V,500mA(Optional:1000mA,2100mA)
Continuous Power 300W 600W 1200W 1500W 2000W 3000W
Peak Power 600W 1200W 2400W 3000W 4000W 6000W
Output Wave Pure Sine Wave
THD ≤5%
Effiency ≥85%
Input Under
Voltage
Alarm		 DC 12V Input DC 10.2-10.8V
DC 24V Input DC 20.4-21.6V
Input Under
Voltage
Shut Down		 DC 12V Input DC 9.2-9.8V
DC 24V Input DC 18.4-19.6V
Input Over
Voltage
Shut Down		 DC 12V Input DC  15-16V
DC 24V Input DC   30-32V
Ambient Temperature 5-35℃
Cooling Method Fan
Input Protection Reverse Polarity (Fuse),Under Voltage,Over Voltage
Output Protection Short Circuit,Overload,Over Temperature
G.W.(kgs) 9.6 11.3 12.1 12.2 8 10
N.W.(kgs) 9.0 10.8 11.6 11.7 7.5 9.5
Size(mm) 205x203x78 237x203x78 335x203x78 335x203x78 335x250x180 335×250×180
Packing(ctn) 5pcs 5pcs 3pcs 3pcs 1pc 1pc
Meas(cm) 66×26×24.5 66×29×24.5 40×39.5×24. 40×39.5×24.5 39×31.5×25 39×31.5×25

分类： ,

描述

Model No PSW8300 PSW8600 PSW81200 PSW81500 PSW82000 PSW83000
Input Voltage DC 12V (DC 11-15V)
DC 24V(DC 22-30V)
Output Voltage AC 100V±10%,AC 110V±10%,AC 220-240V
Output Frequency 55±3Hz,6O±3Hz,50±3Hz
USB Output DC 5V,500mA(Optional:1000mA,2100mA)
Continuous Power 300W 600W 1200W 1500W 2000W 3000W
Peak Power 600W 1200W 2400W 3000W 4000W 6000W
Output Wave Pure Sine Wave
THD ≤5%
Effiency ≥85%
Input Under
Voltage
Alarm		 DC 12V Input DC 10.2-10.8V
DC 24V Input DC 20.4-21.6V
Input Under
Voltage
Shut Down		 DC 12V Input DC 9.2-9.8V
DC 24V Input DC 18.4-19.6V
Input Over
Voltage
Shut Down		 DC 12V Input DC  15-16V
DC 24V Input DC   30-32V
Ambient Temperature 5-35℃
Cooling Method Fan
Input Protection Reverse Polarity (Fuse),Under Voltage,Over Voltage
Output Protection Short Circuit,Overload,Over Temperature
G.W.(kgs) 9.6 11.3 12.1 12.2 8 10
N.W.(kgs) 9.0 10.8 11.6 11.7 7.5 9.5
Size(mm) 205x203x78 237x203x78 335x203x78 335x203x78 335x250x180 335×250×180
Packing(ctn) 5pcs 5pcs 3pcs 3pcs 1pc 1pc
Meas(cm) 66×26×24.5 66×29×24.5 40×39.5×24. 40×39.5×24.5 39×31.5×25 39×31.5×25
