YR2 series thermal relay is suitable for using in the circuit rated voltage up to 660V, ratedcurrent 93A AC 50/ 60Hz, for over-current protection of AC motor. The relay has the differential mechanism and temperature compensation and can plug in YC2 series AC contactor. The product conforms to IEC60947-4-1 stardand.
YR2 series thermal relay is suitable for using in the circuit rated voltage up to 660V, ratedcurrent 93A AC 50/ 60Hz, for over-current protection of AC motor. The relay has the differential mechanism and temperature compensation and can plug in YC2 series AC contactor. The product conforms to IEC60947-4-1 stardand.
| Model | YR2-150, YR2-200, YR2-25, YR2-36, YR2-630, YR2-93 |
|---|---|
| Current Range(A) | 1301 0.1-0.16, 1302 0.16-0.25, 1303 0.25-0.4, 1304 0.4-0.63, 1305 0.63-1, 1306 1-1.6, 1307 1.6-2.5, 1308 2.5-4, 1310 4-6, 1312 5.5-8, 1314 7-10, 1316 9-13, 1321 12-18, 1322 17-25, 2353 23-32, 2355 30-40, 3322 17-25, 3353 23-32, 3355 30-40, 3357 37-50, 3359 48-65, 3361 55-70, 3363 63-80, 3365 80-93, 4365 80-104, 4367 95-120, 4369 110-140, 5369 90-150, F5357 30-50, F5363 48-80, F5367 60-100, F5369 90-150, F5371 132-220, F7375 200-330, F7379 300-500, F7381 380-630 |
